Guide Thermal Monocular TRACKIR 35

£1,649.95

Out of stock

SKU: GUIDETRACKIR35 Category:

Description

Guide Thermal Monocular TRACKIR 35 description

The TrackIR Series of thermal imaging monocular features a 400×300 17µm <50mK NETD thermal sensor & image enhancement for performance imaging combined with a 50Hz refresh rate and a 1280×960 HD LCOS display resulting in a smooth & crisp viewing experience. The TrackIR 35 has a native magnification of 2.3x, with a digital zoom of 4x, resulting in a 9.2x total magnification which alongside the units long distance detection (Humans: 1000m, Vehicles: 2400m) makes this unit perfect as a thermal spotter.

Features a built-in stadiametric rangefinder for measuring the distance of known objects as well as Picture-in-Picture (PiP) mode which adds a zoomed-in display-box within the main viewfinder, this allows the user to hone-in on their subject whilst maintaining full awareness of the wider field of view.

The unit has an internal Li-Ion battery pack with an operating time of up to 5 hours and can be recharged via USB Cable.

The TrackIR Series can also connect to a smartphone via a dedicated App, this allows the unit to be operated remotely, share captured photos & videos as well as be live viewed.

Guide Thermal Monocular TRACKIR 35 Specifications

  • Thermal Sensor: 400×300 17µm <50mK NETD
  • Spectral Range: 8µm-14µm
  • Detection Range: 1000m (Human: 1.8mx0.5m), 2400m (Vehicle: 2.3mx2.3m)
  • Magnification: 2.3x-9.2x
  • Digital Zoom: 1x-4x (Smooth)
  • Focus: 35mm/F1.2 (Manual)
  • Field of View: 11.1°x8.3°
  • Display: 1280×960 (0.4″) LCOS Colour
  • Dioptre: -4 to +2
  • Frame Rate: 50Hz
  • Colour Palettes: White hot, black hot, iron red, blue hot, red hot
  • Scene Modes: Enhanced, Highlight, Natural
  • Picture-in-Picture Mode: Yes
  • Power: Internal Li-Ion (2×18650 6000mAh)
  • Operating Time: >5h
  • Ports: Micro-USB-C, Video Out, Memory Card Slot
  • Internal Memory: 16GB
  • Operating Temperature: -10? to 50?
  • Protection: IP66
  • Drop Rating: 1m
  • Weight: 485g
  • Dimensions: 192x65x71mm



Additional Functions

  • Photo & Video Capture
  • Hotspot Tracking
  • Stadiametric Rangefinder
  • Wi-Fi/ App
  • Compensation Modes: Auto comp./ shutter comp./ scene comp.
  • Indicate Box: Red, yellow, green (coordinates of the indicator box are adjustable)
  • Image Enhancement
  • Brightness & contrast
  • Auto power-off
  • Auto sleep
  • Super power-save mode
  • Indicator off



Includes

  • Thermal Imager
  • USB Cable
  • Micro HDMI Cable
  • Lens Cover
  • Wrist Strap
  • Lining Package
  • Quick Start Guide
