Infiray Iray Thermal Spotter Eye 2 Series V2.0 E3 MAX


Eye II Series To activate this unit’s laser function, press and hold down the Image mode, Digital zoom and Photo buttons until you hear the shutter working (approx.10s). Press and hold the Image mode button to open the laser pointer and the repeat the procedure to close it.


  • Model E3 Max V2.0
  • Resolution, pixels 384×288
  • Pixel Size, μm 12
  • NETD, mk ≤40
  • Frame Rate, Hz 50
  • Objective Lens, mm 35
  • Field of View 7.5°×5.7°
  • Display 1280×960 LCOS
  • Optical Magnification, x 3.5-14.0
  • Digital Zoom, x 2x – 4x
  • Max. Battery Life, h 7
  • Built in Memory (gb) 16
  • Dimension, mm 185x65x64
  • Weight, g <420
  • Detection Range, m 1818

1 in stock

SKU: IRAYE3MAXV2 Category:


Infiray Iray Thermal Spotter Eye 2 Series V2.0 E3 MAX description:

High Image Quality
The Eye? series are embedded with IRay independently developed high performance Vox detector which allows you to get high detailed thermal images, it will be much simpler to search targets in darkness.  There are two kinds of detector resolutions for options: 384*288 & 640*512. The Eye? series has excellent performance in critical temperature range.

HD Micro Display
1280×960 high resolution display that offers crisp image and vivid colors.

Long Detection Range
Depending on model, the V2.0 series is capable of detecting an average human-size target, dressed in outerwear, at a range up to 2600m in complete darkness.

Standby Function
When it is necessary to temporarily stop observation the user can apply standby function. It provides the necessary level of camouflage (no light from the eyepiece of the device) between observation sessions as well as the fast restart of observation (when display is turned off, all other systems are working; for normal operation it is enough just to power on the display again).

High Image Frequency
And the 50Hz refresh rate guarantees you to capture every moment that you are interested.

PIP Functions
Picture-in-Picture improves accuracy by providing a 2x magnified image of the reticle area at the top of the display. It helps to zoom in on a target while retaining the rest of the field of view visible.

5 Color Palettes
The Eye II series provides more than 5 color palettes for true colorized temperature mapping, including “white hot” “black hot” “red hot” “color” and “hot target highlight”. Switching between different color palettes is fast and easy.

Stadiametric Rangefinder
Based on estimated heights of targets user can get the rough distance from the target with the build-in stadiametric rangefinder fast and easy.

Hot Target Tracking
Track the hottest spot in the scene automatically and discover the target quickly.

Built-in Video Recorder and WiFi Connection
The Infiray Iray Thermal Spotter Eye 2 Series V2.0 E3 MAX  has 16 GB build-in memory to store the captured still images and video recording and WiFi module which allows 4 connections simultaneously.

Apple & Android App Link- CLICK HERE

User Manual- CLICK HERE
